Astral Fire Pro for Enhanced Protection

05 Jul 2024

Understanding the Role of Advanced CPVC Pipes for Fire Sprinklers

Fire sprinkler systems are crucial for rapid and effective fire response, safeguarding lives and property. These automated systems swiftly detect and suppress fires, minimising damage and preventing the spread of flames. Their proactive role in fire safety underscores their vital importance in both residential and commercial structures.ย

When it comes to fire safety, the role of advanced technologies and materials cannot be overstated. Among these innovations, Astral Fire Pro stands out as a cutting-edge CPVC piping system designed specifically for fire sprinkler installations.

Let’s explore the features and benefits that make Astral Fire Pro the new industry standard for automatic fire sprinkler piping systems.

Astral Fire Pro for Fire Sprinkler Systems

Astral Fire Pro pipes and fittings are engineered from Chlorinated Polyvinyl Chloride (CPVC), a specialised thermoplastic known for its exceptional fire-resistant properties. The use of Astral Fire Pro in sprinkler installations offers a host of advantages, making it a preferred choice for architects, engineers and contractors alike.

Certifications and Approvals

Astral Fire Pro holds the prestigious IS:16088 certification and is C-UL certified, attesting to its compliance with rigorous industry standards. Approved for use in various settings, including light and ordinary hazardous rooms, as outlined by NFPA 13, Astral Fire Pro is suitable for a wide range of applications in both new constructions and retrofit projects.

This versatility makes it an ideal solution for fire sprinklers in high-rise residential and commercial structures, schools, institutions, one and two-family dwellings, as well as hotels and hospitals.

Key Features and Benefits

  1. High Flash Ignition Temperature: Astral Fire Pro CPVC boasts a flash ignition temperature of 480ยฐC, significantly higher than ordinary combustibles. This property ensures that the fire sprinklers system cannot be the ignition source of a fire, enhancing overall safety.
  2. Limiting Oxygen Index (LOI): With an exceptionally high LOI of 60, Astral Fire Pro CPVC will not sustain burning unless constantly exposed to a flame. This feature, coupled with its resistance to flame spread, makes it a reliable choice for fire sprinkler systems.
  3. Superior Hydraulic Capabilities: The Hazen-Williams friction coefficient of C=150 ensures Astral Fire Pro’s smooth interior surface minimises friction loss, allowing the use of smaller pipe diameters and material cost savings.
  4. Corrosion Resistance: Astral Fire Pro pipes exhibit excellent resistance to corrosion, making them suitable for harsh environmental conditions and ensuring long-term durability.
  5. Low Smoke Generation: In the event of a fire, Astral Fire Pro CPVC pipe and fittings produce low smoke, contributing to a safer evacuation environment.
  6. Temperature/Pressure Rating: With a continuous service rating of 175 psi at 150ยฐF (65ยฐC), Astral Fire Pro pipes and fittings are suitable for a wide range of ambient temperatures.

Fields of Application and Specifications

Astral Fire Pro is approved for use in various settings, including schools, institutions, malls, commercial complexes, hospitals, offices, hotels and high-rise buildings. Meeting standards such as ASTM F442, IS 16534, ASTM F439 and being UL Listed, Astral Fire Pro ensures reliability and compliance.

In the dynamic landscape of fire safety, Astral Fire Pro emerges as the new industry standard for automatic fire sprinkler piping systems, its advanced CPVC technology enhances safety and revolutionises the efficiency and performance of fire sprinkler installations. With features that prioritise ignition resistance, hydraulic capabilities and corrosion resistance, Astral Fire Pro can undeniably be at the forefront of safeguarding lives and properties in diverse built environments.

Exploring CPVC for the first time? Our blog on The ย Benefits of Using CPVC Pipes and Fittings for Fire Sprinkler Systems is a must-read.
